| Machine model |
unit |
FA-V6 |
FA-V8 |
FA-V1270 |
FA-V1370 |
FA-V1380 |
FA-V1680 |
| worktable size |
mm |
700×420 |
1000×500 |
1400×700 |
1400×700 |
1400×800 |
1800×800 |
| T-slot |
|
14T*3*125 |
18T*5*80 |
18T*5*125 |
18T*5*125 |
18T*5*125 |
18T*6*130 |
| Max. loading |
kg |
250 |
450 |
700 |
700 |
700 |
1300 |
| X axis travel |
mm |
600 |
800 |
1200 |
1300 |
1300 |
1600 |
| Y axis travel |
mm |
450 |
500 |
700 |
700 |
800 |
800 |
| Z axis travel |
mm |
450 |
550 |
700 |
700 |
700 |
700 |
| spindle nose to worktable |
mm |
135-585 |
120-670 |
120-820 |
120-820 |
120-820 |
120-970 |
| spindle to column guides |
mm |
488 |
550 |
770 |
770 |
860 |
860 |
| spindle taper/diam. |
|
BT40(Φ120) |
BT40(Φ155) |
BT40(Φ155) |
BT40(Φ155) |
BT40(Φ155) |
BT50(Φ150) |
| spindle speed |
rpm/min |
12000rpm direct drive |
12000rpm direct drive |
8000rpm belt drive |
8000rpm belt drive |
8000rpm belt drive |
8000 rpm direct drive |
| spindle servomtor |
kw |
7.5/11 |
7.5/11 |
11/15 |
11/15 |
11/15/opt: 15/18.5 |
15/18.5 |
| CNC control |
|
Fanuc 0i MF(5) |
Fanuc 0i MF(5) |
Fanuc 0i MF(5) |
Fanuc 0i MF(5) |
Fanuc 0i MF(5) |
Fanuc 0i MF(5) |
| X/Y/Z rapid feed |
m/min |
48/48/48 |
48/48/48 |
36/36/36 |
36/36/36 |
36/36/36 |
48/48/48 |
| Cutting speed |
m/min |
1-12 |
1-12 |
1-12 |
1-12 |
1-8 |
1-8 |
| positioning accuracy |
mm |
±0.004mm |
±0.004mm |
±0.005mm |
±0.005mm |
±0.006mm |
±0.006mm |
| repeatability |
mm |
±0.003mm |
±0.003mm |
±0.004mm |
±0.004mm |
±0.005mm |
±0.005mm |
| guides(linear width/blocks Qty) |
|
XY:30*2 Z:35*2 |
XYZ:35*2 |
XZ：45*3 Y:45*2 |
XZ：45*3 Y:45*2 |
XZ：45*3 Y:45*2 |
XYZ：45ball tyep/roller type |
| Z axis balancing |
|
without nitrogen balancing system |
option：nitrogen balancing system |
|
| weight approxiamte |
KG |
4500 |
5100 |
7000 |
7300 |
8000 |
11000 |
