| Item | unit | FA4230HX | FA6230HX | ||
| Worktable& travel | Worktable size | mm | 4200*2800 | 6000*2800 | |
| T slot width | mm | 22 | 22 | ||
| Max.Load of worktable | Kg | 6000/㎡ | 6000/㎡ | ||
| Gantry width | mm | 3900 | 3900 | ||
| Spindle nose to worktable | mm | 300-1550 | 300-1550 | ||
| X axis travel | mm | 4200 | 6600 | ||
| Y axis travel | mm | 3200 | 3200 | ||
| Z axis travel | mm | 1250 | 1250 | ||
| Spindle | Taper | HSK-A100 | HSK-A100 | ||
| Spindle speed | r/min | 10000 | 10000 | ||
| Spindle motor | KW | 30 | 30 | ||
| Swiveling head | A axis swiveling range | ±110° | ±110° | ||
| C axis swiveling range | ±360° | ±360° | |||
| A axis rated/Max.torque | 700/1060Nm | 700/1060Nm | |||
| C axis rated/Max.torque | 715/1350Nm | 715/1350Nm | |||
| Max. speed | 60rpm | 60rpm | |||
| Positioning accuracy | 8” VDI3441 | 8” VDI3441 | |||
| repeatability | 4” VDI3441 | 4” VDI3441 | |||
| Feed | Rapid feed | X | m/min | 10 | 10 |
| Y | m/min | 10 | 10 | ||
| Z | m/min | 10 | 10 | ||
| Cutting feed | XYZ | m/min | 8 | 8 | |
| Feed motor torque | X | KW | 8.6*2pcs | 8.6*2pcs | |
| Y | KW | 8.6 | 8.6 | ||
| Z | KW | 8.6 | 8.6 | ||
| guideway | X | Roller linear guideway 55width 4pcs | Roller linear guideway 55width 4pcs | ||
| Y | Roller linear guideway 55width 4pcs | Roller linear guideway 55width 4pcs | |||
| Z | Roller linear guideway 45width 4pcs | Roller linear guideway 45width 4pcs | |||
| Accuracy | Positioning accuracy | x/y/z | mm | 0.01/500 | 0.01/500 |
| Repeatability | x/y/z | mm | 0.006/500 | 0.006/500 | |
| Machine weight（±5%) | T | 55 | 68 | ||
| CNC control | HNC 848Di | HNC 848Di | |||
