| ltem machine type | FA-2520HX | FA-3020HX | |
| journey | X-axis | 2700mm | 3000mm |
| Y-axis | 2000mm | 2000mm | |
| Z-axis | 1000mm | 1000mm | |
| Distance from spindle nose to worktable | 400-1400mm | 400-1400mm | |
| workbench | Workbench area | 2500*2000mm | 3000*2000mm |
| Maximum load of workbench | 8T/㎡ | 6T/㎡ | |
| T-slot size (width * number) | 10-18/180mm | 7-22/180mm | |
| Gantry structure | width | 3050mm | 4205mm |
| Spindle | Spindle speed | 10000change | 10000change |
| Spindle specifications | HSK/A100 | HSK/A100 | |
| Control System | Standard configuration | HNC-848Di | HNC-848Di |
| X1 axis servo motor | 9.9KW/47NM | 7105/48NM | |
| X2 axis servo moto | 9.9KW/47NM | 7105/48NM | |
| Y-axis servo motor | 9.9KW/47NM | 7105/48NM | |
| Z-axis servo motor | 9.9KW/47NM | 7105/48NM | |
| Spindle power | 54KW (rated 200NM) | 54KW (rated 200NM) | |
| A-axis parameters | Torque motor power and speed | Maximum torque 1060Nm/60rpm | Maximum torque 1060Nm/60rpm |
| C-axis parameters | Torque motor power and speed | Maximum torque 1350Nm/60rpm | Maximum torque 1350Nm/60rpm |
| Comprehensive detailed parameters of swing head | For details, see the Iberg parameter list | -------- | |
| Tool measuring system | Renishaw | ||
| Grating scale parameters (XYZ) | Spanish Fagor LC115 absolute value | 4 sticks | 4 sticks |
| A axis | Spanish Fagor RCN2380 absolute value | 1 sticks | 1 sticks |
| C axis | Spanish Fagor RCN8380 absolute value | 1 sticks | 1 sticks |
| A/C axis hydraulic brake system | 100kg | Tongxing Assembly | Tongxing Assembly |
| XYZ positioning accuracy | 1000mm/0.01mm | 500mm/0.01mm | |
| XYZ repeat positioning accuracy | 1000mm/0.005mm | 500mm/0.005mm | |
| A-axis positioning accuracy | ±5" | ±5" | |
| C-axis positioning accuracy | ±3" | ±3" | |
| A/C/spindle cooling method | Water cooling (fill with Mobil high-performance antifreeze) | ||
| Three-axis roller linear rail parameters (mm) | X1.X2 | Φ55/2. Φ55/2 | Φ45/2. Φ45/2 |
| Y | Φ55/4 | Φ45/4 | |
| Z | Φ45/4 | Φ45/4 | |
| Three-axis ball screw parameters (mm) | X1.X2 | Φ63/1. Φ63/1 | Φ50/1. Φ50/1 |
| Y | Φ63/1 | Φ63 | |
| Z | Φ50 | Φ50 | |
| Tool magazine (optional umbrella shape) | Tool allowance | 20T | 20T |
| Maximum tool length | 250mm | 250mm | |
| Maximum tool diameter | 30mm | 30mm | |
| Maximum tool weight | 5KG | 5KG | |
| Chip removal | Two snails and one chain | ||
| Movement rate | Rapid movement rate (X/Y/Z) | 12/12/12m/min | 12/12/12m/min |
| chip feed rate | 0-10000 | 0-10000 | |
| Machine tool protective cover | Machinery Group | Machinery Group | |
| Machine weight | About 40T | About 44T | |
| Machine size (mm) | 4800*5100*5150 | 6705*5458*4886mm | |
